Upgraded Atom Uprights

These uprights are machined from billet aluminum and feature larger sealed bearings, high strength heat-treated drive hubs and ARP wheel studs. They are much stronger and stiffer than stock. Despite this the weight difference versus stock is less than a pound. Kits are available for both US and UK built Atoms. With these uprights premature bearing failures and twisted uprights are no longer an issue.

For ordering information contact: m@palatov.com

#1000300

Atom Rear Upright Complete Set Brammo

$1500.00

#1000301

Atom Rear Upright Complete Set UK 4 x 3.75

$1500.00

#1000302

Atom Rear Upright Complete Set UK 4 x 100

$1500.00

#1000303

Atom Rear Bracket Set Alcon 4

$250.00

#1000304

Atom Rear Bracket Set Wilwood 11"

$250.00

#1000305

Atom Rear Bracket Set Wilwood 10"

$250.00

#1000306

Atom Rear Bracket Set PBR

$250.00

#1000307

Atom Parking Brake Bracket, 7/16 - 14 Set

$250.00

#1000308

Atom Parking Brake Bracket, M10 - 1.5 Set

$250.00

Click For More Info

Atom Progressive-rate Bellcrank Kit

Replaces original regressive-rate bellcranks with billet aluminum units featuring a progressive rate. These bellcranks also feature roller thrust bearings for reduced friction and longer life. The kit greatly reduces the chance of suspension overtravel and prevents bellcrank and frame failures. The new geometry delivers improved compliance over small road irregularities while limiting body roll and excessive suspension travel. Upgraded pushrods are recommended.

$800.00

For ordering information contact: m@palatov.com

Click For More Info

Atom Upgraded Pushrod Kit

The upgraded pushrods feature larger, stronger rodends (Aurora AM-8T and AB-8T) that are more appropriate for the application than the stock units. The kit is compatible with both standard and upgraded bellcranks (recommended).

$500.00

For ordering information contact: m@palatov.com

Click For More Info

Atom Combined Bellcrank and Pushrod Kit

Ugraded bellcranks and pushrods in a combined package at a reduced price vs. buying separately.

$1200.00

For ordering information contact: m@palatov.com

Click For More Info

Atom Chassis Brace Kit

For Brammo-produced cars only.  The kit ties the rear subframe to the under-seat cross tube significantly improving chassis rigidity.  Requires cutting of the fiberglass tub and some drilling of the underseat cross-tube for Rivnut installation.  Available by special order only.

$500.00

For ordering information contact: m@palatov.com
